PPD-AR5BXB6

FCC ID

Equipment: 802.11abg module

Qualcomm Atheros, Inc. -AR5BXB6

1700 Technology Dr, San Jose, CA 95110 United States

Application
Frequency Range
Final Action Date
Granted
nI/l/uMzPZ2gn0XSLhI7zw==
2412.0-2462.0
2006-10-27
FAILED
nI/l/uMzPZ2gn0XSLhI7zw==
5745.0-5825.0
2006-10-27
FAILED
mS5ASE5cONzh7CXuRMyySQ==
5180.0-5320.0
2006-10-27
FAILED
aiJfDkg1kLr1tKk936MYzw==
2412.0-2462.0
2005-07-14
APPROVED
aiJfDkg1kLr1tKk936MYzw==
5745.0-5825.0
2005-07-14
APPROVED
SALWFekeB65FJaZIIRiedw==
5180.0-5320.0
2005-07-14
APPROVED
H1U1MwacRbvZbUXU45CK0A==
5180.0-5320.0
2006-11-07
APPROVED
TICjMIuGBd0lJgvTt87eBw==
2412.0-2462.0
2006-11-07
APPROVED
TICjMIuGBd0lJgvTt87eBw==
5745.0-5825.0
2006-11-07
APPROVED
v2wkXwT6hi1Uy/cEJjusjQ==
2412.0-2462.0
2007-01-09
APPROVED
v2wkXwT6hi1Uy/cEJjusjQ==
5745.0-5825.0
2007-01-09
APPROVED
0modbYTIX+gs9/um8yCFtg==
5150.0-5350.0
2007-01-09
APPROVED
hxxrIxUkZGwmdlB1dfaqPQ==
2412.0-2462.0
2007-04-13
APPROVED
hxxrIxUkZGwmdlB1dfaqPQ==
5745.0-5825.0
2007-04-13
APPROVED
3ZgwSqPG9hSRNxMOJfdwrg==
5180.0-5320.0
2007-04-13
APPROVED
IIiq+QDM8fwepESmPlobFw==
5180.0-5240.0
2007-06-29
APPROVED
IIiq+QDM8fwepESmPlobFw==
5260.0-5320.0
2007-06-29
APPROVED
IIiq+QDM8fwepESmPlobFw==
5500.0-5700.0
2007-06-29
APPROVED
LAQNeH05TbeBkI5o67ElLQ==
5180.0-5240.0
2007-07-03
APPROVED
LAQNeH05TbeBkI5o67ElLQ==
5260.0-5320.0
2007-07-03
APPROVED
LAQNeH05TbeBkI5o67ElLQ==
5500.0-5700.0
2007-07-03
APPROVED
QMWFV0bX/uiM+XT6ZelQYQ==
2412.0-2462.0
2007-07-03
APPROVED
QMWFV0bX/uiM+XT6ZelQYQ==
5745.0-5825.0
2007-07-03
APPROVED
4uJQQe1hl2q5bL4hYp9H9Q==
5180.0-5240.0
2007-07-17
APPROVED
4uJQQe1hl2q5bL4hYp9H9Q==
5260.0-5320.0
2007-07-17
APPROVED
4uJQQe1hl2q5bL4hYp9H9Q==
5500.0-5700.0
2007-07-17
APPROVED
File NameDocument TypeDateDirect
SAR attachment 4RF Exposure Info 2007-07-17 00:00:00 pdf
SAR attachment 3RF Exposure Info 2007-07-17 00:00:00 pdf
SAR attachment 2RF Exposure Info 2007-07-17 00:00:00 pdf
SAR attachment 1RF Exposure Info 2007-07-17 00:00:00 pdf
SAR ReportRF Exposure Info 2007-07-17 00:00:00 pdf
Setup PhotosTest Setup Photos 2007-07-17 00:00:00 pdf
Test ReportTest Report 2007-07-17 00:00:00 pdf
User ManualUsers Manual 2007-07-17 00:00:00 pdf
RF Exposure JustificationRF Exposure Info 2007-07-17 00:00:00 pdf
Host PC InfoCover Letter(s) 2007-07-17 00:00:00 pdf
Class II Permissive Change LetterCover Letter(s) 2007-07-17 00:00:00 pdf
Request for ConfidentialityCover Letter(s) 2007-07-17 00:00:00 pdf
Agent Authorization LetterCover Letter(s) 2007-07-17 00:00:00 pdf
ManualUsers Manual 2007-07-03 00:00:00 pdf
Host LabelID Label/Location Info 2007-07-03 00:00:00 pdf
Authorization LetterCover Letter(s) 2007-07-03 00:00:00 pdf
Test Setup PhotosTest Setup Photos 2007-06-29 00:00:00 pdf
TCB Q and ACover Letter(s) 2007-06-29 00:00:00 pdf
ID labelID Label/Location Info 2007-06-29 00:00:00 pdf
Class II permissive change cover letterCover Letter(s) 2007-06-29 00:00:00 pdf
Confid RequestCover Letter(s) 2007-04-13 00:00:00 pdf
Revised Confid RequestCover Letter(s) 2007-04-13 00:00:00 pdf
SAR SetupTest Setup Photos 2007-05-28 00:00:00 pdf
NII SetupTest Setup Photos 2007-05-28 00:00:00 pdf
Part 2Test Report 2007-04-13 00:00:00 pdf
Part 1Test Report 2007-04-13 00:00:00 pdf
Appendix F3RF Exposure Info 2007-04-13 00:00:00 pdf
Appendix F2RF Exposure Info 2007-04-13 00:00:00 pdf
Appendix F1RF Exposure Info 2007-04-13 00:00:00 pdf
Appendix E6RF Exposure Info 2007-04-13 00:00:00 pdf
Appendix E5RF Exposure Info 2007-04-13 00:00:00 pdf
Appendix E4RF Exposure Info 2007-04-13 00:00:00 pdf
Appendix E3RF Exposure Info 2007-04-13 00:00:00 pdf
Appendix E2RF Exposure Info 2007-04-13 00:00:00 pdf
Appendix E1RF Exposure Info 2007-04-13 00:00:00 pdf
Appendix DRF Exposure Info 2007-04-13 00:00:00 pdf
Appendix CRF Exposure Info 2007-04-13 00:00:00 pdf
LabelID Label/Location Info 2007-04-13 00:00:00 pdf
Host PC Info 2External Photos 2007-05-28 00:00:00 pdf
Agent AuthorizationCover Letter(s) 2007-04-13 00:00:00 pdf
Purpose of FilingCover Letter(s) 2007-04-13 00:00:00 pdf
SAR Test SetupTest Setup Photos 2007-05-28 00:00:00 pdf
DTS Test SetupTest Setup Photos 2007-05-28 00:00:00 pdf
Module LabelingID Label/Location Info 2007-04-13 00:00:00 pdf
Host OverviewExternal Photos 2007-05-28 00:00:00 pdf
Reason for ChangeCover Letter(s) 2007-04-13 00:00:00 pdf
REPLY COMMENTCover Letter(s) 2007-01-09 00:00:00 pdf
reply letterCover Letter(s) 2007-01-09 00:00:00 pdf
SAR report - 06LR020SAR-F cont4RF Exposure Info 2007-01-09 00:00:00 pdf
SAR report - 06LR020SAR-F cont3RF Exposure Info 2007-01-09 00:00:00 pdf
SAR report - 06LR020SAR-F cont2RF Exposure Info 2007-01-09 00:00:00 pdf
SAR report - 06LR020SAR-F cont1RF Exposure Info 2007-01-09 00:00:00 pdf
SAR report - 06LR020SAR-FRF Exposure Info 2007-01-09 00:00:00 pdf
Dipole calibrationRF Exposure Info 2007-01-09 00:00:00 pdf
probe calibrationRF Exposure Info 2007-01-09 00:00:00 pdf
SAR report - 06U10632-4B -- 06U10632-4RF Exposure Info 2007-01-09 00:00:00 pdf
SAR report - 06U10631-3BRF Exposure Info 2007-01-09 00:00:00 pdf
SAR report - 06U10630-3BRF Exposure Info 2007-01-09 00:00:00 pdf
rf exposureRF Exposure Info 2007-01-09 00:00:00 pdf
test reportTest Report 2007-01-09 00:00:00 pdf
host pc labelID Label/Location Info 2007-01-09 00:00:00 pdf
module labelID Label/Location Info 2007-01-09 00:00:00 pdf
setup photoTest Setup Photos 2007-01-09 00:00:00 pdf
internal eutInternal Photos 2007-01-09 00:00:00 pdf
external eutExternal Photos 2007-01-09 00:00:00 pdf
manualUsers Manual 2007-02-23 00:00:00 pdf
confidentiality letterCover Letter(s) 2007-01-09 00:00:00 pdf
application letterCover Letter(s) 2007-01-09 00:00:00 pdf
authorization letterCover Letter(s) 2007-01-09 00:00:00 pdf
RF exposure infoRF Exposure Info 2007-01-09 00:00:00 pdf
labelID Label/Location Info 2007-01-09 00:00:00 pdf
Internal photInternal Photos 2007-01-09 00:00:00 pdf
External photoExternal Photos 2007-01-09 00:00:00 pdf
SAR reportRF Exposure Info 2007-01-09 00:00:00 pdf
Application letterCover Letter(s) 2007-01-09 00:00:00 pdf
Authorization letterCover Letter(s) 2007-01-09 00:00:00 pdf
Revised Confid Request LetterCover Letter(s) 2006-11-07 00:00:00 pdf
Test Setup photosTest Setup Photos 2006-12-22 00:00:00 pdf
Page 51 to 83Test Report 2006-11-07 00:00:00 pdf
Page 1 to 50Test Report 2006-11-07 00:00:00 pdf
Page 61 to 80RF Exposure Info 2006-11-07 00:00:00 pdf
Page 45 to 60RF Exposure Info 2006-11-07 00:00:00 pdf
Page 1 to 45RF Exposure Info 2006-11-07 00:00:00 pdf
SAR Probe 3RF Exposure Info 2006-11-07 00:00:00 pdf
SAR Probe 2RF Exposure Info 2006-11-07 00:00:00 pdf
SAR Probe 1RF Exposure Info 2006-11-07 00:00:00 pdf
Dipole Cal 4RF Exposure Info 2006-11-07 00:00:00 pdf
Dipole Cal 3RF Exposure Info 2006-11-07 00:00:00 pdf
Dipole Cal 2RF Exposure Info 2006-11-07 00:00:00 pdf
Dipole Cal 1RF Exposure Info 2006-11-07 00:00:00 pdf
Internal labelingID Label/Location Info 2006-11-07 00:00:00 pdf
Internal Host PC InfoInternal Photos 2006-12-22 00:00:00 pdf
Ext PhotosExternal Photos 2006-11-07 00:00:00 pdf
Purpose of ApplicationCover Letter(s) 2006-11-07 00:00:00 pdf
SAR 61 to 80RF Exposure Info 2006-11-07 00:00:00 pdf
SAR 45 to 60RF Exposure Info 2006-11-07 00:00:00 pdf
SAR 1 to 45RF Exposure Info 2006-11-07 00:00:00 pdf
Probe 3RF Exposure Info 2006-11-07 00:00:00 pdf
Probe 2RF Exposure Info 2006-11-07 00:00:00 pdf
Probe 1RF Exposure Info 2006-11-07 00:00:00 pdf
Users ManualUsers Manual 2006-12-22 00:00:00 pdf
SAR Dipole Data 4RF Exposure Info 2006-11-07 00:00:00 pdf
SAR Dipole Data 3RF Exposure Info 2006-11-07 00:00:00 pdf
SAR Dipole Data 2RF Exposure Info 2006-11-07 00:00:00 pdf
SAR Dipole Data 1RF Exposure Info 2006-11-07 00:00:00 pdf
Card LabelingID Label/Location Info 2006-11-07 00:00:00 pdf
Host PC Info PhotosInternal Photos 2006-12-22 00:00:00 pdf
Reason for FilingCover Letter(s) 2006-11-07 00:00:00 pdf
dimissal letterCover Letter(s) pdf
supplementCover Letter(s) pdf
updateCover Letter(s) pdf
confidential requestCover Letter(s) pdf
supplement for form731Cover Letter(s) pdf
Cover letterCover Letter(s) pdf
Set up photosTest Setup Photos 2005-08-28 00:00:00 pdf
Test reportTest Report 2005-07-14 00:00:00 pdf
MPERF Exposure Info 2005-07-14 00:00:00 pdf
Internal photosInternal Photos 2005-08-28 00:00:00 native
FCC ID labelID Label/Location Info 2005-07-14 00:00:00 pdf
External photosExternal Photos 2005-08-28 00:00:00 pdf
modular requestCover Letter(s) 2005-07-14 00:00:00 pdf
POACover Letter(s) 2005-07-14 00:00:00 pdf
Request for confidentialityCover Letter(s) 2005-07-14 00:00:00 pdf
Modular request letterCover Letter(s) 2005-07-14 00:00:00 pdf
BOIS LOCKOperational Description N/A
Antenna infoParts List/Tune Up Info N/A
Bios LockOperational Description N/A
WLAN Antenna InfoParts List/Tune Up Info N/A

Application Details:

Equipment802.11abg module
FRN0003716743
Grantee CodePPD
Product Code-AR5BXB6
Applicant BusinessQualcomm Atheros, Inc.
Business Address1700 Technology Dr , San Jose,California United States 95110
TCB Scope
TCB Email
ApplicantPaul Guckian – Vice President, Regulatory Engineering
Applicant Phone
Applicant Fax858-651-1547
Applicant Email[email protected]
Applicant MailStop
Test FirmInternational Standards Laboratory
Test Firm ContactGrace Lai
Test Firm Phone 29
Test Firm Fax886-2-264-64641
Test Firm Email[email protected]
Certified ByMichael Green – Director
Comment [0modbYTIX+gs9/um8yCFtg==]: Power Output listed is Conducted. Modular Approval. This transmitter must be used indoors when operating in the 5150MHz to 5250MHz frequency range. This module contains a BIOS lock and may be installed by the end user. When used in mobile RF exposure conditions, the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. For use in portable RF exposure conditions, SAR compliance was demonstrated for device with specific antenna(s) in specific computer(s) and co-located conditions as described in filings under this FCC ID; other antenna configurations require separate co-location and SAR routine evaluations where applicable. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. The highest reported single and co-transmit body SAR values for filings under this FCC ID are: 2.4 GHz-band 0.20 W/kg; 5.2 GHz-band 0.17 W/kg; 5.8 GHz-band 0.19 W/kg; co-transmit 1.11 W/kg.
Comment [3ZgwSqPG9hSRNxMOJfdwrg==]: Power Output listed is Conducted. Modular Approval. This module contains a BIOS lock and may be installed by the end user. When used in RF category Mobile configurations, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. When used in RF category Portable configurations, this authorization is limited to ThinkPad X60 and ThinkPad X61 tablet computers. The antenna used for this transmitter may be collocated with the BT module FCC ID: MCLJ07H081. Simultaneous transmission or co-location with any other transmitter in excess of specified handoff time is prohibited. End users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This transmitter must be used indoors when operating in the 5150 to 5250 MHz band. The highest reported SAR values are: Body: 0.203 W/kg
Comment [4uJQQe1hl2q5bL4hYp9H9Q==]: Class II Permissive Change to allow specific Portable configuration in the 5470 - 5725 MHz band. Power Output listed is Conducted. Modular Approval. This module contains a BIOS lock and may be installed by the end user. When used in RF category Mobile configurations, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. The antenna used for this transmitter in the ThinkPad T61 computer may be collocated with the UWB module FCC ID: MCLT60H990 as documented in this filing. When used in RF category Portable configurations, this authorization is limited to ThinkPad X60 and ThinkPad X61 tablet computers. The antenna used for this transmitter may be collocated with the BT module FCC ID: MCLJ07H081. Simultaneous transmission or co-location with any other transmitter in excess of specified handoff time is prohibited. End users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This transmitter must be used indoors when operating in the 5150 to 5250 MHz band. The highest reported SAR values are: Body: 0.203 W/kg
Comment [aiJfDkg1kLr1tKk936MYzw==]: Power Output listed is Conducted. Modular approval. This module is approved for use in mobile only configurations. This module contains a BIOS lock and may be installed by the end user. The antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. The antenna used for this transmitter may be collocated with the BT module FCC ID: MCLJ07H081, and must not be collocated or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
Comment [H1U1MwacRbvZbUXU45CK0A==]: Power Output listed is Conducted. Modular Approval. This module contains a BIOS lock and may be installed by the end user. When used in an RF category Mobile environment, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. When used in an RF category Portable environment, this device has shown compliance when installed exclusively in a tablet computer as listed in this filing. The antenna used for this transmitter may be collocated with a Bluetooth transmitter module FCC ID: MCLJ07H081; it must not be collocated or operating in conjunction with any other antenna or transmitter within the host device. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. The highest reported SAR values are: Body worn: 0.203W/kg. This transmitter must be used indoors when operating in the 5150MHz to 5250MHz frequency range.
Comment [hxxrIxUkZGwmdlB1dfaqPQ==]: Power Output listed is Conducted. Modular Approval. This module contains a BIOS lock and may be installed by the end user. When used in RF category Mobile configurations, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. When used in RF category Portable configurations, this authorization is limited to ThinkPad X60 and ThinkPad X61 tablet computers. The antenna used for this transmitter may be collocated with the BT module FCC ID: MCLJ07H081. Simultaneous transmission or co-location with any other transmitter in excess of specified handoff time is prohibited. End users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This transmitter must be used indoors when operating in the 5150 to 5250 MHz band. The highest reported SAR values are: Body: 0.203 W/kg
Comment [IIiq+QDM8fwepESmPlobFw==]: Class II Permissive Change to include DFS capabilities, disable HT40 operation in DFS bands, add 5500 - 5700 MHz band for Mobile RF Exposure configurations as documented in this filing. Power Output listed is Conducted. Modular Approval. This module contains a BIOS lock and may be installed by the end user. When used in RF category Mobile configurations, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. The antenna used for this transmitter in the ThinkPad T61 computer may be collocated with the UWB module FCC ID: MCLT60H990 as documented in this filing. When used in RF category Portable configurations, this authorization is limited to ThinkPad X60 and ThinkPad X61 tablet computers. The antenna used for this transmitter may be collocated with the BT module FCC ID: MCLJ07H081. Simultaneous transmission or co-location with any other transmitter in excess of specified handoff time is prohibited. End users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This transmitter must be used indoors when operating in the 5150 to 5250 MHz band. The highest reported SAR values are: Body: 0.203 W/kg
Comment [LAQNeH05TbeBkI5o67ElLQ==]: Class II Permissive Change filing. Modular Approval. Power Output listed is Conducted. This module contains a BIOS lock and may be installed by the end user. This transmitter is approved for Mobile RF Exposure configurations in 5500 - 5700 MHz band and HT40 operation is disabled in DFS bands. When used in RF category Mobile configurations, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. The antenna used for this transmitter may be collocated with a Bluetooth transmitter module FCC ID: MCLJ07H081 and a UWB transmitter module FCC ID: MCLT60H990, and must not be collocated or operating in conjunction with any other antenna or transmitter within the host device. When used in RF category Portable configurations, this authorization is limited to ThinkPad X60 and ThinkPad X61 tablet computers. End users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This transmitter must be used indoors when operating in the 5150 to 5250 MHz band. The highest reported SAR values are: Body: 0.203 W/kg
Comment [QMWFV0bX/uiM+XT6ZelQYQ==]: Class II permissive change filing. Modular Approval. Power Output listed is Conducted. This module contains a BIOS lock and may be installed by the end user. When used in an RF category Mobile environment, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. When used in an RF category Portable environment, this device has shown compliance when installed exclusively in a tablet computer as listed in this filing. The antenna used for this transmitter may be collocated with a Bluetooth transmitter module FCC ID: MCLJ07H081 and a UWB transmitter module FCC ID: MCLT60H990; it must not be collocated or operating in conjunction with any other antenna or transmitter within the host device. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. The highest reported SAR values are: Body worn: 0.203W/kg.
Comment [SALWFekeB65FJaZIIRiedw==]: Power Output listed is Conducted. Modular approval. This module is approved for use in mobile only configurations. This module contains a BIOS lock and may be installed by the end user. The antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. The antenna used for this transmitter may be collocated with the BT module FCC ID: MCLJ07H081, and must not be collocated or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This transmitter must be used indoors when operating in the 5150MHz to 5250MHz frequency range.
Comment [TICjMIuGBd0lJgvTt87eBw==]: Power Output listed is Conducted. Modular Approval. This module contains a BIOS lock and may be installed by the end user. When used in an RF category Mobile environment, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. When used in an RF category Portable environment, this device has shown compliance when installed exclusively in a tablet computer as listed in this filing. The antenna used for this transmitter may be collocated with a Bluetooth transmitter module FCC ID: MCLJ07H081; it must not be collocated or operating in conjunction with any other antenna or transmitter within the host device. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. The highest reported SAR values are: Body worn: 0.203W/kg.
Comment [v2wkXwT6hi1Uy/cEJjusjQ==]: Power Output listed is Conducted. Modular Approval. This transmitter must be used indoors when operating in the 5150MHz to 5250MHz frequency range. This module contains a BIOS lock and may be installed by the end user. When used in mobile RF exposure conditions, the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. For use in portable RF exposure conditions, SAR compliance was demonstrated for device with specific antenna(s) in specific computer(s) and co-located conditions as described in filings under this FCC ID; other antenna configurations require separate co-location and SAR routine evaluations where applicable. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. The highest reported single and co-transmit body SAR values for filings under this FCC ID are: 2.4 GHz-band 0.20 W/kg; 5.2 GHz-band 0.17 W/kg; 5.8 GHz-band 0.19 W/kg; co-transmit 1.11 W/kg.
