OXP324-TX

FCC ID

Equipment:

The Toro Company 324-TX

5825 Jasmine Street, Riverside, CA 92504 United States

Application Frequency Range	Final Action Date Granted
QcV1aq1tQYm4nfaiEX+wFQ== 433.0-433.0	2000-03-27 APPROVED

File Name	Document Type	Date	Direct
FCC label and location	ID Label/Location Info	2000-03-27 00:00:00	jpeg
IS conf chip side of transmitter PCA	Internal Photos	2000-03-27 00:00:00	jpeg
IS conf antenna side of transmitter PCA	Internal Photos	2000-03-27 00:00:00	jpeg
IS conf solder side of main PCA	Internal Photos	2000-03-27 00:00:00	jpeg
IS config chip side of main PCA	Internal Photos	2000-03-27 00:00:00	pdf
IS config dip side of dip PCA	Internal Photos	2000-03-27 00:00:00	pdf
IS config solder side of dip PCA	Internal Photos	2000-03-27 00:00:00	jpeg
IS config all PCAs removed	Internal Photos	2000-03-27 00:00:00	jpeg
IS config bottom with bottom cover and dip cover removed	Internal Photos	2000-03-27 00:00:00	jpeg
IS config bottom side with bottom cover removed	Internal Photos	2000-03-27 00:00:00	jpeg
IS config bottom side	Internal Photos	2000-03-27 00:00:00	jpeg
IS config top side	Internal Photos	2000-03-27 00:00:00	jpeg
AI config chip side of transmitter PCA	Internal Photos	2000-03-27 00:00:00	jpeg
AI config antenna side of transmitter PCA	Internal Photos	2000-03-27 00:00:00	jpeg
AI config solder side of main PCA	Internal Photos	2000-03-27 00:00:00	jpeg
AI config chip side of main PCA	Internal Photos	2000-03-27 00:00:00	jpeg
AI config dip side of dip PCA	Internal Photos	2000-03-27 00:00:00	jpeg
AI config solder side of dip PCA	Internal Photos	2000-03-27 00:00:00	jpeg
AI config all PCAs removed	Internal Photos	2000-03-27 00:00:00	jpeg
AI config bottom side with bottom cover and dip cover removed	Internal Photos	2000-03-27 00:00:00	jpeg
AI config bottom side with botom cover removed	Internal Photos	2000-03-27 00:00:00	jpeg
AI config bottom side	External Photos	2000-03-27 00:00:00	jpeg
AI config top side	External Photos	2000-03-27 00:00:00	jpeg
CKC Test Report	Test Report	2000-03-27 00:00:00	pdf
User guide	Users Manual	2000-03-27 00:00:00	pdf
System block	Block Diagram	2000-03-27 00:00:00	pdf
Transmitter and receiver block	Block Diagram	2000-03-27 00:00:00	pdf
Label makeup	ID Label/Location Info	2000-03-27 00:00:00	pdf
Expository statement	Operational Description	2000-03-27 00:00:00	pdf
Drug compliance letter	Cover Letter(s)	2000-03-27 00:00:00	pdf
Agent authorization letter	Cover Letter(s)	2000-03-27 00:00:00	pdf
Request for confidentiality	Cover Letter(s)	2000-03-27 00:00:00	pdf
all three pages of shcematics to remain confidential	Schematics		N/A

Application Details:

Equipment	EZ-Remote or Irritrol Systems Kwikstart RC
FRN	0014042428
Grantee Code	OXP
Product Code	324-TX
Applicant Business	The Toro Company
Business Address	5825 Jasmine Street , Riverside,California United States 92504
TCB Scope
TCB Email
Applicant	Dan Yee – Quality Manager - Agency Compliance
Applicant Phone
Applicant Fax	909-785-3754
Applicant Email	[email protected]
Applicant MailStop
Test Firm	CKC Laboratories, Inc.
Test Firm Contact	Steve Behm
Test Firm Phone	2221
Test Firm Fax	866-779-9776
Test Firm Email	[email protected]
Certified By	Tracy Phillips – Documentation Control Supervisor
